Glomex Oasis TV aerial wall mount automatic amplifier
Product Code: T480AGC
With conventional amplifiers, in fact, you have to manually adjust the tv signal gain by lowering the amplification when the signal is high and by increasing the amplification when you are far from the tv transmitter. with the new oasis agc, everything will happen automatically and the innovative amplifier can be placed in a hidden location inside the rv. oasis agc is easy to install and provided with all necessary accessories for installation: support for roof installation, 5m (16.5’) coaxial cable, 1,5m (5’) tv cable and agc amplifier.
*supplied accessories:
• Automatic amplifier
• 5 m (16,4') coaxial cable to connect the antenna with the amplifier
• 1,5 m (5') coaxial cable to connect the amplifier to the tv / decoder
• Nylon roof mount (code t198) – 150x150mm
*technical specifications
• Antenna dimensions; 250 x 205 mm (10x8'')
• Base diameter; 25 mm (1'')
• Antenna weight; 350g (12,34oz)
• Angle of reception; 360°
• Frequency range; 40/890 mhz
• Gain average; 26 db
• Noise factor; 2,2 db
• Impedance; 75 ohms
• Amplifier adjustable gain; Yes
• Amplifier by-pass; No
• Power consumption; 20 ma
• Power supply; 12/24 vdc
• Tv set max; 2
• Radome type; U.V. resistant asa
• Termination; F connector
• Polarization; Horizontal and vertical
Materials and Dimensions
Technical Information
SKU: T480AGC
Barcode: 8051566302215
Brand: Glomex
